[JAVA] Vector를 활용한 그래픽 에디터

Shape.class

package Ex03;

public abstract  class Shape {
	private Shape next;
	public Shape() {
		next=null;
	}
	public Shape getNext() {
		return next;
	}
	public Shape(Shape next) {
		this.next = next;
	}
	public abstract void draw();
}



Rect.class

package Ex03;

public class Rect extends Shape{
	@Override
	public void draw() {
		System.out.println("Rect");
	}
}



Line.class

package Ex03;

public class Line extends Shape{
	@Override
	public void draw() {
		System.out.println("Line");
	}
}



Circle.class

package Ex03;

public class Circle extends Shape{
	@Override
	public void draw() {
		System.out.println("Circle");
	}
}



GraphicEdit.class

package Ex03;

import java.util.Scanner;
import java.util.Vector;

public class GraphicEdit {
	private Scanner sc = new Scanner(System.in);
	/*
	 벡터를 3개 만들어야 하지만 다형성을 이용해서 1개만 만듬
	 */
	private Vector<Shape> v = new Vector<>();

	private void run() {
		System.out.println("그래픽 에디터를 실행합니다.");
		int choice = 0;
		while(choice != 4) {
			System.out.println("삽입(1), 삭제(2), 모두보기(3), 종료(4)");
			int type, index;
			choice = sc.nextInt();
			switch(choice) {
			case 1: //삽입
				System.out.println("Line(1), Rect(2), Circle(3)");
				type = sc.nextInt();
				if(type < 1 || type > 3) {
					System.out.println("잘못 선택했습니다.");
					break;
				}
				insert(type);
				break;
			case 2: //삭제
				System.out.println("삭제할 도형의 위치 >> ");
				index = sc.nextInt();
				if(!delete(index)) {
					System.out.println("삭제 할 수 없습니다.");
				}
				break;
			case 3: //모두보기
				view();
				break;
			case 4: //종료
				break;
			default :
				System.out.println("잘못된 번호를 입력했습니다. 다시 입력하세요.");
			}
		}
	}
	private void insert(int choice) {
		Shape shape = null;
		switch (choice) {
		case 1:
			shape = new Line();
			break;
		case 2:
			shape = new Rect();
			break;
		case 3:
			shape = new Circle();
			break;
		default:
			System.out.println("잘못된 번호를 입력했습니다. 다시 입력하세요.");
		}
		v.add(shape);
	}
	private boolean delete(int index) {
		if(v.size() == 0 || index >= v.size()) {
			return false;
		}
		v.remove(index);
		return true;
	}
	private void view() {
		for(int i=0; i<v.size(); i++) {
			v.get(i).draw();
		}
	}
	public static void main(String[] args) {
		GraphicEdit ge = new GraphicEdit();
		ge.run();

	}
}
